Wolf Tooth Elliptical 104 BCD Chainring - 36t 104 BCD 4-Bolt Drop-Stop A BLK
$71.95
SKU
CR0191
UPC
Wolf Tooth Elliptical 104 BCD Chainring - 36t 104 BCD 4-Bolt Drop-Stop Black. Designed for 104 BCD Mountain Cranksets. The proprietary design has an ovality of 10% and a timing of 112 degrees after top dead center which provide the benefits of an oval ring without the traditional downsides of oval rings. This chainring features the patent pending asymmetrical Drop-Stop tooth design for the best in wear life mud clearance and chain retention.The simplest way to explain the way these rings feel is having 2 teeth less in the weak part of your pedal stroke and 2 teeth more where you have the most power
Drop-Stop chainrings are designed for use with 1x9 1x10 1x11 and 1x12 drivetrains
Compatible with all 10- 11- and 12-speed chains with the exception of Shimano 12-speed chains
Shimano 12-speed chains require the use of Wolf Tooth's Shimano 12-speed specific chainrings
If using a 9-speed drivetrain use a 10-speed chain which will provide a tighter fit for better chain retention
Made from 7075-T6 aluminum for long life
These rings are threaded use with 10mm chainring bolts
48mm - 50mm chainline depending on the crankset
- TECH SPECS
| Tooth Count | 36 |
| Ring Position/Type | Chain Retaining Single Ring |
| Drivetrain Speeds | 9 |
| Drivetrain Speeds | 10 |
| Drivetrain Speeds | 11 |
| Drivetrain Speeds | 12 |
| Chainring BCD | 104 |
| Color | Black |
| Defined Color | Black |
| Material | Aluminum |
