KEY PERFORMANCE FACTORS
Accelerate faster
The heart of the Langma Advanced is a super-light Advanced-grade composite frameset, delivering a powerful stiffness-to-weight ratio for explosive acceleration. Updated truncated ellipse tubing reduces wind drag and boosts sprinting efficiency.
Better handling
Integrated, flat-mount disc brakes deliver the confidence to carry speed into corners and navigate variable weather conditions. The Langma also accommodates tires up to 32mm, so you can customize your set-up for the road ahead.
Vibration canceling
The tubeless Giant SLR 36 Disc WheelSystem (select models) reduces drag, while the adjustable Variant Composite Seatpost provides superior compliance, so you get a responsive ride that practically skims over rough roads.
SPECS
| Sizes |
XXS, XS, S, M, L
|
| Colors |
Liquid Metal, AI Blue
|
| Frame |
Advanced-grade composite, 12x142mm thru-axle, disc
|
| Fork |
Advanced-grade composite, full-composite OverDrive steerer, 12x100mm, disc
|
| Shock | N/A |
| Handlebar |
Liv Contact XXS: 360mm, XS: 360mm, S: 380mm, M: 400mm, L: 420mm
|
| Grips | Liv All Condition |
| Stem |
Giant Contact XXS: 80mm, XS: 80mm, S: 90mm, M: 100mm, L: 110mm
|
| Seatpost |
Giant Variant, composite XXS: 357mm, XS: 357mm, S: 357mm, M: 357mm, L: 357mm
|
| Saddle | Liv Approach |
| Pedals | N/A |
| Shifters | Shimano 105 |
| Front Derailleur | Shimano 105 |
| Rear Derailleur | Shimano 105 |
| Brakes |
Shimano 105 hydraulic, Giant MPH rotors [F]160mm, [R]140mm
|
| Brake Levers |
Shimano 105 hydraulic
|
| Cassette |
Shimano 105, 12-speed, 11x34
|
| Chain | KMC X12 |
| Crankset |
Shimano 105, 34/50 XXS: 165mm, XS: 165mm, S: 170mm, M: 170mm, L: 172.5mm
|
| Bottom Bracket |
Shimano, press fit
|
| Rims |
Giant P-R2 Disc wheelset
|
| Hubs |
Giant P-R2 Disc wheelset, 12mm thru-axle
|
| Spokes | Sapim |
| Tires |
Giant Course 1, tubeless, 700x25c (28mm), folding
|
| Extras |
tubeless prepared, 32mm max tire size
|
| Weight |
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
|
SIZING GUIDE AND GEOMETRY
Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
| XXS | XS | S | M | L | ||
| A | SEAT TUBE LENGTH (mm) | 390 | 420 | 450 | 480 | 510 |
| B | SEAT TUBE ANGLE | 75.0° | 75.0° | 74.5° | 74.0° | 73.5° |
| C | TOP TUBE LENGTH (mm) | 498 | 508 | 524 | 540 | 555 |
| D | HEAD TUBE LENGTH (mm) | 105 | 120 | 135 | 155 | 175 |
| E | HEAD TUBE ANGLE | 70.0° | 71.0° | 72.0° | 72.5° | 72.5° |
| F | FORK RAKE (mm) | 49 | 49 | 49 | 49 | 49 |
| G | TRAIL (mm) | 74.3 | 67.8 | 61.4 | 58.2 | 58.2 |
| H | WHEELBASE (mm) | 970 | 973 | 977 | 984 | 996 |
| I | CHAIN STAY LENGTH (mm) | 405 | 405 | 405 | 405 | 405 |
| J | BOTTOM BRACKET DROP (mm) | 72 | 72 | 70 | 70 | 67 |
| K | STACK (mm) | 499 | 517 | 532 | 553 | 569 |
| L | REACH (mm) | 364 | 370 | 377 | 382 | 386 |
| M | STAND OVER HEIGHT (mm) | 680 | 700 | 730 | 760 | 790 |
| N | HANDLEBAR WIDTH (mm) | 360 | 360 | 380 | 400 | 420 |
| O | STEM LENGTH (mm) | 80 | 80 | 90 | 100 | 110 |
| P | CRANK LENGTH (mm) | 165 | 165 | 170 | 170 | 172.5 |
| Q | WHEEL SIZE | 700C | 700C | 700C | 700C | 700C |
